In this video I show you how to replace a blade on a Sears Craftsman Edger 550 series model #247.772461. Replacing an Edger Blade is very easy if you have the right tools. I’m being a little dramatic because you really only need a wrench and a pair of pliers. My dad would say something like we only had wrenches and ratchets and we loved it! But now we have all types of battery powered impact drivers and impact guns to choose from. And they are amazing. You can work more efficiently and not have to worry about a pneumatic hose.
Replacing an Edger Blade
I used an impact driver, a 1/2″ impact adapter, and a 15/16″ impact socket. The threads are normal threads on the blade shaft – to loosen turn the flange nut counterclockwise and to tighten turn the nut clockwise. The replacement blade is part number 781-0748-0637. Using the impact driver made it easier to loosen the flange nut than using a ratchet and socket and holding the hex bolt (edger blade shaft) with pliers. In case you didn’t know – I love this impact driver!
Find this product and others relating to Edgers & Maintenance here: U Do It™ Edgers and Maintenance List on Amazon(opens in a new window)
- Part Number：781-0748 781-0748-0637 40-009 490-105-M017 981-0748, Fits the Following Models: Troy-Bilt TB554, TEB515
- Center Hole: 5/8" Length: 9" Width:9"
- Also for 9 inch (5/8 in. round center hole) Craftsman SBD CMXGZAM105017 Tri-Arc Blade, Replaces 981-0748, 781-0748, 7185767
Amazon.com Price last update on 2026-11-03 - Details(This link opens in a new window)
0:00 Intro
0:07 Sears Craftsman Edger 550 Blade
0:20 15/16″ Impact Socket to Remove Blade
0:50 Securing shaft with pliers to remove bolt
1:05 Installation of new blade
1:36 Matt’s Amazing Testimonial
The blade is typically the first bit of maintenance that needs to be performed on an edger. If you have a long perimeter of sidewalk, patio, or pavement the blade will wear quickly. As you know, you’ll be grinding your edger blade against the concrete. I recommend buying two blades so you don’t have to wait.
Maintenance Beyond the Blade
Chances are high you already know these. If you don’t, then these can help you. Some chemicals you’ll need is a degreaser, starting fluid and carb cleaner. You’ll also need engine oil, a funnel, and an oil pan to drain and refill the oil. I also recommend Oil Dri (website)(opens in a new window) and Scott Shop Towels or equivalent. You’ll need engine oil on hand, starting fluid, and carb cleaner. You may need to flush out the fuel from the tank at the start of the season and replace or add a fuel filter. At the end of the season you’ll want to add fuel stabilizer to the tank and to your gas can.
Electric Powered Edgers
The maintenance of electric-powered edgers is much less than that of gas-powered edgers. You have
- blade
- battery
- control board
- trigger
- bearings/belt or just the motor if it is direct drive
If your edger is serviceable and the bearings fail, you can purchase replacement bearings and install them. If the motor fails, do you buy a replacement motor OR do you buy a new edger? This is the trade-off. If a gas engine fails due to a gasket, water in the gas, or a bad spark plug – these are all things that can be service. However, for certain models parts are nearly impossible to purchase. And with our supply chain disruption it is even more difficult to source parts. Combine this with the big push against gas powered equipment you’ll have no choice but to go with electric.
I love electric. But, I hate that we line in a “throw-away economy”. Just throw it away if it is broken. Then go and buy a new one.
